Eaton Emergency Lighting UPS
Uninterruptible Power Supply

Eaton UL UPS

Emergency Lighting UPS
277V split-phase
Emergency Lighting UPS, 277V 10 kVA / 7.2 kW
Emergency Lighting UPS, 277V 15 kVA / 9 kW
208V three-phase
Emergency Lighting UPS, 208V 10 kVA / 8.5 kW
Emergency Lighting UPS, 208V 15 kVA / 13.1 kW
Emergency Lighting UPS, 208V 20 kVA / 18 kW
Emergency Lighting UPS, 208V 30 kVA / 24 kW
Emergency Lighting UPS, 208V 30 kVA / 27 kW
480V/277V three-phase
Emergency Lighting UPS, 480V 20 kVA / 18 kW
Emergency Lighting UPS, 480V 30 kVA / 24 kW
Emergency Lighting UPS, 480V 30 kVA / 27 kW

Overview:

Emergency lighting requirements and related building codes are vital in commercial structures to facilitate occupant egress during a building fire or other emergency situation. Eaton's emergency lighting UPSs are UL 924 tested and certified, providing the industry's highest capacity and smallest footprint solution.

Eaton's Emergency Lighting UPS solutions are perfect for:

  • Hospitals
  • Schools
  • Government buildings
  • Office buildings
  • Manufacturing facilities
  • Hotels
  • Commercial buildings

Eaton meets the strict standards for UL 924 Compliance

Providing you confidence in your emergency lighting solution

90 minutes of backup

  • All Eaton emergency lighting UPS solutions are configured with external line and match battery cabinets to provide 90 minutes of backup time, which is required by the UL 924 standard

Manually operated test switch

  • The emergency lighting product line features manually operated test switches for conducting the mandated standard equipment tests.

Protected test switch and interface

  • In accordance with the standard, the manually operated test switch and interface are protected from accidental operation and protected from non-authorized users.

In order to avoid building/safety code inspection delays during the commissioning of new facilities or retrofits of existing facilities, emergency lighting systems must be UL 924 listed. Remember only systems supplied from one manufacturer that are tested and approved by UL can carry the UL 924 listing.

Eaton's UPSs are backed by an extensive service network of over 240 field technicians, providing prompt service, full maintenance and stocked replacement parts not available from other vendors or providers.

Connectivity & manageability

Enhanced communication capabilities

UL 924 UPSs are equipped with a variety of standard communications features for network connectivity and remote management applications, including:

  • RS-232 serial port
  • Two X-SlotĀ® communication bays
  • Relay output contacts
  • Two programmable signal inputs

Centralized control and visibility

Intelligent Power Manager software for monitoring

Eaton's Intelligent Power Manager (IPM) software allows the consolidation of monitoring and management of your emergency lighting UPSs. Any PC with an Internet browser and network connection can access status and power conditions of Eaton's emergency lighting UPSs, providing you the comfort that your systems are operating correctly.

IPM software is free for monitoring up to 10 devices. For locations with more than 10 devices, licenses can be purchased based on the number of units to be monitored.

Service:

Proven warranty and support services

Customers consistently rank Eaton number one in providing quality service; our comprehensive, world-class solutions are designed to improve costs, uptime, reliability, power quality and safety. With 240 field service technicians in North America and 1,200 international authorized service providers, Eaton has more service personnel than any other UPS manufacturer, coverage that ensures your emergency lighting and egress solutions are addressed in a timely fashion. The standard factory warranty covers:

  • System warranty: One year parts / 90 days labor
  • Battery warranty: Two years parts / 90 days labor

Extensive service options for enhanced reliability

For support beyond the warranty period, Eaton offers enhanced service options including onsite startup, corrective and preventive maintenance, battery solutions, training, remote monitoring and factory spare parts and upgrades. Customizable three-phase UPS services packages allow customers to select the plan that provides the right combination of system uptime, convenience and value.

eNotify Remote Monitoring

Eaton's optional eNotify Remote Monitoring Service provides 24x7 real-time monitoring of the UPS and battery systems and alerts both service technicians and the customer when a problem is detected. Proactive monitoring enables technical experts to respond immediately to more than 40 alarm conditions and, in many cases, resolve issues remotely with minimal or no downtime. Additional eNotify benefits include:

  • One-way outbound status and event e-mails for security and reliability
  • Fast diagnosis and notification of critical alarms
  • Monthly customer reports including power event logs and overall UPS and battery health summaries

Specifications:

Product Snapshot
Power Rating 10-30 kVA
Voltage 208/277/480 Vac
Frequency 50/60 Hz
Configuration Tower
Product Series Powerware
277V split-phase
Part Number Power Rating(VA/Watts) Input Plug Output Receptacles
277V 10 kVA / 7.2 kW
10000 / 7200 Hardwired Hardwired
277V 15 kVA / 9 kW
15000 / 9000 Hardwired Hardwired
208V three-phase
Part Number Power Rating(VA/Watts) Input Plug Output Receptacles
208V 10 kVA / 8.5 kW
10000 / 8500 Hardwired Hardwired
208V 15 kVA / 13.1 kW
15000 / 13100 Hardwired Hardwired
208V 20 kVA / 18 kW
20000 / 18000 Hardwired Hardwired
208V 30 kVA / 24 kW
30000 / 24000 Hardwired Hardwired
208V 30 kVA / 27 kW
30000 / 27000 Hardwired Hardwired
480V/277V three-phase
Part Number Power Rating(VA/Watts) Input Plug Output Receptacles
480V 20 kVA / 18 kW
20000 / 18000 Hardwired Hardwired
480V 30 kVA / 24 kW
1000 / 600 Hardwired Hardwired
480V 30 kVA / 27 kW
1500 / 900 Hardwired Hardwired

Documentation:

Download the Eaton UL 924 Spec Sheet (PDF).

Download the Intelligent Power Software Suite Brochure (PDF).
